Product Highlights
The Chroma 63206A series high power electronic loads with digital signal microprocessor built in have the optimal speed and control performance designed for testing a wide range of power conversion products. The DC loads have unique user defined waveform (UDW) capability and external analog modulating input for simulating realworld, custom waveforms. The 63206A-1200-240 electronic DC loads also have overcurrent, overpower, and over temperature protections as well as over voltage and polarity reverse alarms to enhance product reliability.
Each model of the Chroma 63206A-1200-240 has 3 power ranges so they can precisely measure the voltage and current in real time. The 300% peak overpower capability provides extra headroom for fault condition simulations in automotive batteries, fuel cells, and more. Its super high voltage (0.015%+0.015%F.S.) and current (0.04%+0.04%F.S.) measurement accuracy ensures the fidelity of results. The Chroma 63206A-1200-240 electronic loads operate in constant voltage, current, resistance, or power modes to satisfy a wide range of test requirements. When the need is for increased power, two or more loads can be run in parallel to achieve the desired load current.
Specifications for the Chroma 63206A-1200-240 Programmable DC Electronic load include:
| |
Low |
Mid |
High |
| Voltage |
| 0-1200V | |
| Current |
0-24A |
0-120A |
0-240A |
| Power |
| 0-6000W | |
| Min Operating Voltage |
2V@24A |
10V@120A |
20V@240A |
