SigVSA is a professional vector signal analysis software application that runs on both Windows and Linux operating systems. With SigVSA, users can repeatedly analyze signals under test and quickly troubleshoot issues, covering everything from simple BPSK to complex wideband signals such as 4G LTE, 5G NR, IEEE 802.11b/a/g/n/ac/ax/be, and 4096QAM. SigVSA offers rich measurement capabilities, a user-friendly operation experience, and an interactive interface similar to that of a vector signal analyzer, ensuring both efficiency and ease of use. It provides comprehensive local analysis functionality, supporting offline analysis of raw waveform files from vector signal analyzers. SigVSA enables remote vector signal analysis and debugging on a computer, allowing simultaneous control of multiple instruments for parallel operation. It also facilitates centralized processing of recorded data or simulation files, saving time by reducing the need for lab visits.
The Siglent SIGV-VSAN1 refers to a node/node-group software license for the SigVSA Vector Signal Analysis software by Siglent. This software is designed for analyzing and demodulating digital and analog RF signals when paired with compatible Siglent test instruments (like Spectrum Analyzers or Oscilloscopes).
- Comprehensive Modulation Analysis: Evaluation of digital and analog modulation schemes.
- Vector Signal Analysis: Deep-dive measurements into magnitude, phase, and signal quality.
- Intuitive UI: Visualization tools like constellation diagrams, eye diagrams, and error vector magnitude (EVM) displays
Applications
- 5G New Radio (NR) Signal Analysis
- RF Testing and Verification
- Research & Development
Each Unit Includes
- 5G NR/NR-A Modulation Analysis (SIGV-VSAN1)
