The Keysight DP5700 Series DC power supplies are compact and secure, delivering the right performance in space-constrained lab and production environments. The series includes 92 single-output programmable models, with 1.5 kW units in half-rack width and 3.4 kW, 5 kW and 7.5kW units in full-rack width, both only 1U high. They provide stable output with built-in voltage and current measurements, with operating ranges up to 600 V / 150 A (on the 1.5 kW models), 600 V / 340 A (on the 3.4 kW models), 600 V / 500 A (on the 5 kW models) and 1500V/375A (on the 7.5kW models). The DP5700 Series is equipped with a removable SD memory, which supports sensitive security applications, enabling safe movement of test equipment between confidential spaces.
The Keysight DP5783AL is a high-density, programmable DC power supply belonging to the Keysight DP5700 series. Engineered for demanding automated test environments and space-constrained labs, it delivers high-power testing capabilities while occupying minimal rack space.
- Voltage: 30V
- Current: 250 A
- Small high-density 1U package
- Built-in voltage and current measurements
- Comprehensive protection from overvoltage and overcurrent
- Single-phase 100 – 240 VAC universal input for 1.5 kW models
- Single- and three-phase 200 – 240 VAC, and three-phase 380 – 480 VAC universal input for 3.4 kW
- Three-phase 200 – 240 VAC, and three-phase 380 – 480 VAC universal input for 5 kW and 7.5kW models
- Standard LAN, USB, and GPIB interfaces
- Full compliance with the LXI Class C specification
- Removable SD card option for added security
Applications
- Aerospace and Defense
- Automotive & Electromobility
- Automated Test Equipment
- Semiconductor & Industrial
Each Unit Includes
- DC Power Supply, 30V (DP5783AL)
