Keysight 8496B-001 Type N (F) Connectors

Order # 8496B-001 | Mfg # 8496B-001
$0.00
Call for price

Tariff fees or manufacture imposed surcharges may be applicable.

This product is available for shipping to the United States and Canada only.

Overview

Product Highlights

  • Frequency range: dc to 18 GHz
  • Insertion loss at 0 dB: 0.6 dB + 0.09 dB/GHz
  • Maximum SWR: 1.5 to 8 GHz, 1.6 to 12.4 GHz, 1.9 to 18 GHz
  • Repeatability life: 0.03 dB max 5 million cycles per section, typical
  • 5 million cycles per section
  • Maximum RF input power: 1 W (average), 100 W (peak)
  • Connect in series with 11716A Attenuator Interconnect Kit, Type-N
