The NS-600 LED Stroboscope is designed to measure the speed of a rotating object or one that is cycling in a linear repetitive pattern without contact or reflective tape. When the flash rate and rpm rate are identical, the target will appear "frozen" visually. If the flash rate it adjusted slightly, the target would be put into slow motion for detailed motion analysis, observation or trouble-shooting.
The NS-600 features a rugged cast-Aluminum housing, the latest LED technology and compact size making it a perfect choice for use anywhere on the factory floor. The NS-600 is ideal for speed, motion and vibration analysis, such as rotating shafts, fans, cams, etc. NS-600 automatically adjusts flash duration for ultra high speed and features a user-selectable flash duration for those applications where the user wants to optimize either the image "sharpness" or increase the "brightness" to the highest levels.
- Extended battery life of 8 hours continuous use at 6,000 fpm/rpm
- Adjustable Flash Duration
- Highly stable drift free operation
- Auto wide measuring range – up to 120,000 fpm/rpm
- Push button operation with x2 and ÷2 buttons for quick adjustment
- Store up to 10 flash rates in memory for records or quick retests
- Rugged aluminum housing - compact size
- Easy-to-read 5 digit 0.47" (12 mm) high LCD
- External trigger input and output
- Tripod mountable
Applications
- Rotating Shafts
- Fans/ Blowers
- Cams / Conveyor Chains / Pulleys
- Production Lines
Each Unit Includes
- NS-600 LED Stroboscope
- 2 x AA Batteries
- Plastic Carrying Case
