The UNI-T USG3000M-PG is a specialized narrow pulse generator option for the USG3000M series RF signal generators. This advanced option enhances the USG3000M generator with high-precision, narrow pulse generation capabilities, enabling the creation of extremely short RF pulses essential for automotive radar testing, high-speed digital communications, and advanced research applications.
The USG3000M-PG option can be installed at the time of purchase or added later as an upgrade. For existing units, the option is enabled through a license file installation procedure that can be performed by the user.
- Ultra-Narrow Pulse Width: Generate pulses as narrow as 20 ns with 10 ns resolution
- Precise Timing Control: Fine adjustment of pulse parameters with 10 ns precision
- Extended Pulse Period Range: Create pulse patterns from 40 ns to 42 seconds
- High-Resolution Delay Control: Set pulse delays with 10 ns resolution
- Flexible Triggering Options: Free-running or triggered operation for versatile test setups
- Pulse Modulation Option USG3000M-PM (Sold Separately - and required for complete narrow pulse generation capabilities)
Applications
- Automotive Radar / Millimeter Wave Radar Testing
- High Speed Digital Communications
- Research & Advanced R&D
- Semiconductor / Component Testing
Each Unit Includes
- 1 - Narrow-Pulse Generator Kit (USG3000M-PG)
