Unlock real-time signal injection and waveform creation with the UPO7000LAWG option for UNI-T's UPO7000L Series digital phosphor oscilloscopes. This upgrade enables a built-in 1-channel arbitrary waveform generator - ideal for testing analog circuits, simulating sensors, performing sweep analysis, or injecting waveforms for control loop validation.
With up to 60 MHz output frequency, high-resolution waveform shaping, and modulation support, this option turns the oscilloscope into a complete source-and-measure solution-saving bench space and improving workflow efficiency.
- All-in-One Testing - Stimulus and measurement from the same instrument streamlines setup and saves bench space
- Real-Time Design Feedback - Inject waveforms while monitoring system response to optimize tuning in real time
- Custom Waveform Creation - Load or build test signals for unique circuit responses, including ramp-up/down or glitch conditions
- Bode Plot Ready - Essential for engineers working on switching regulators, feedback loops, or control systems
Applications
- Frequency response analysis (with UPO7000L-PWR - (NOT included))
- Signal injection into analog circuits and filters
- Sensor signal emulation in embedded systems
- Loop tuning and verification in switching power supplies
- Educational demonstrations of waveform theory and modulation
Each Unit Includes
- 1 - Single-Channel 60MHz Arbitrary Waveform Generator Option (UPO7000L-AWG)
