Product Highlights
The Berkeley Nucleonics 7340 is an integrated solution that offers an indispensable set of measurement functions for evaluating signal sources ranging from VHF to microwave frequencies such as crystal oscillators, PLL synthesizers, clocks, phase-locked or free-running VCOs, DROs, SAW or YIG oscillators, and others. The flexible instrument comprises a two-channel cross-correlation system with two internal tunable references sources and also allows measurements with externally fed references. It is a compact and powerful instrument available with LAN (VXI-11), USBTMC, or with GPIB (optionally) interfaces. Platform independent intuitive graphical user interface (GUI), API library, and powerful SCPI command language set are available. The Berkeley Nucleonics 7340 has a frequency range from 1 MHz to 40 GHz.
- Absolute and residual phase noise measurements
- Amplitude noise measurements
- Pulsed absolute and residual phase noise measurements
- Two channel 100 MHz FFT analyzer
- Transient measurements (frequency, phase, amplitude versus time)
- Spectrum analysis
- Frequency counter function / power meter
