Keysight / Agilent E4351B USED FOR SALE
120V, 4A, 480W Solar Array Simulator (SAS), GPIB

Order #: E4351B-USED

Mfg #: E4351B

Questions about availability or need help? Contact Us:

(800) 633-0561
$5,318.67

Keysight / Agilent E4351B USED FOR SALE

120V, 4A, 480W Solar Array Simulator (SAS), GPIB

Order #: E4351B-USED

Mfg #: E4351B

$5,318.67

Request a Used Instrument Quote

Have a Question? Speak to a Transcat Expert: 800.264.4059

Used instruments from TranscatTranscat Used Instrument Guarantee
Calibration Certificate Included 6 Month Warranty Unsurpassed Service & Support

Availability: Ships in 3-4 weeks
This item is available as RENTAL at
Call for price
Shop now

Product highlights

The Keysight E4351B One-Box Solar Array Simulator (SAS) is a dc power source with 480 watt output that simulates the output characteristics of a solar array. The SAS is primarily a current source with very low output capacitance and is capable of simulating the I-V curve of different arrays under various conditions. The I-V curve is programmable over the IEEE-488.2 bus and is conveniently generated within the SAS. Up to 60 volatile / non-volatile tables can be pre-programmed.

Output Ratings (Simulator and Table Modes)

  • Max. Power: 480 W
  • Voc. Max.: 130 V
  • Isc. Max.: 4 A

Output Ratings (for mixed mode)

  • Max Power: 480 W
  • V rated: 0-120 V
  • I rated: 0-4 A

Programming Accuracy at 25°C ±5°C

  • Voltage (Fixed Mode): 0.075% + 20 mV
  • Current (Simulator and Fixed Mode): 0.2% + 10 mA

Ripple & Noise (20 Hz to 20 MHz)

  • Voltage rms: 24 mV
  • Voltage p-p: 195 mV
  • Current rms: 4 mA
