Tohnichi AMRD3Z
Rotary Slip, Adj Torque Driver for Fine Screw, 1-3, 0.05ozf.in

Order #: AMRD3Z

Mfg #: AMRD3Z

Questions about availability or need help? Contact Us:

(800) 633-0561
Special Price $1,227.82 Regular Price $1,306.20

Tohnichi AMRD3Z

Rotary Slip, Adj Torque Driver for Fine Screw, 1-3, 0.05ozf.in

Order #: AMRD3Z

Mfg #: AMRD3Z

Special Price $1,227.82 Regular Price $1,306.20
Availability: Ships in 3-4 weeks

Product Highlights

  • Adjustable Torque Screwdriver for precision tightening of small screws (M1-M2).
  • Easily set torque by twisting body to select torque value
  • Rotary slip mechanism prevents over-torque.
    • User will sense and hear "click" at set torque and should stop turning. If user continues, the rotary slip mechanism will ratchet the driver without applying more torque.
  • Tohnichi's toggle clutch torque mechanism creates enhanced durability and reliability
  • Index finger holding feature allows the operator to tighten with precise movements.
  • Tohnichi bit set included for AMRD models. BMRD accepts standard 1/4" hex root bits (sold separately)
Win a Generac Generator when purchasing $750 or more from Transcat.Win a Generac Generator when purchasing $750 or more from Transcat.
Accuracy ± 3%
S.I. MODEL AMRD1CN AMRD2CN AMRD4CN AMRD8CN BMRD15CN2 BMRD30CN2
TORQUE RANGE
[cN · m]
MIN.~MAX. 0.3~1 0.5~2 1~4 2~8 2~15 4~30
GRAD. 0.01 0.025 0.05 0.1 0.2
METRIC MODEL 100AMRD 200AMRD 400AMRD 800AMRD 1.5BMRD2 3BMRD2
TORQUE RANGE
[gf · cm/kgf · cm]
MIN.~MAX. gf · cm30~100 50~200 100~400 200~800 kgf · cm0.2~1.5 0.4~3
GRAD. gf · cm1 2.5 5 10 kgf · cm0.01 0.02
AMERICAN MODEL - AMRD3Z AMRD6Z AMRD12Z 1.5BMRD2-A 3BMRD2-A
TORQUE RANGE
[ozf · in/lbf · in]
MIN.~MAX. - ozf · in
1~3
2~6 3~12 lbf · in0.2~1.5 0.4~3
GRAD. - ozf · in
0.05
0.1 0.2 lbf · in0.005 0.01
APPLICABLE SCREW SMALL SCREW - M1 (M1.1)M1.2 (M1.4)M1.6 (M1.8) M2(M2.2)
TAPPING SCREW - - M1 (M1.1)M1.2 (M1.4)M1.6 (M1.8)M2
DIMENSION
[mm]
OVERALL LENGTH L' 93 116
GRIP 𝓁1 10 15
BODY 𝓁2 8 11
D3 13 15
𝓁1 72 62
𝓁1 14
𝓁2 8 10
WEIGHT [kg] 0.03 0.05
ACCESSORY BIT + #0
-thickness X width 0.15x1, 0.2x1.5, 0.3x2
