Enerpac RCH123 30259 12-Ton Hydraulic Cylinder
30259 12-Ton Hydraulic Cylinder
Order #: RCH-123
Mfg #: RCH123
$1,839.60
Enerpac RCH123 30259 12-Ton Hydraulic Cylinder
30259 12-Ton Hydraulic Cylinder
Order #: RCH-123
Mfg #: RCH123
Product Highlights
- Hollow plunger design allows for both pull and push forces
- Single-acting spring return
- Nickel-plated, floating center tube on models over 20 tons increases product life
- Baked enamel finish for increased corrosion resistance
- Collar threads for easy fixturing
- Features CR400 Coupler
Cylinder capacity | 12 tons (13.8 maximum) |
Stroke length | 3.00 inches |
Effective area | 2.76 square inches |
Oil capacity | 8.29 cubic inches |
Cylinder bore diameter | 2.13 inches |
Collapsed height | 7.25 inches |
Extended height | 10.25 inches |
Outside diameter | 2.75 inches |
Center hole diameter | 0.77 inches |
Port size | 1/4" NPTF |
Weight | 9.8 lb. |
