PACE 1001B barometer employs digitally characterized pressure sensors which offer the quality, stability and precision associated with this latest generation of resonant devices, providing a measurement you can trust throughout the 12 month calibration cycle.
The PACE 1001B precision barometric indicator brings together the latest measurement technology from Druck to offer an elegant, fast, flexible and cost-effective solution to barometric indication and monitoring.
The PACE 1001B barometer offers four levels of precision to accommodate specification and budget requirements
- Utilizes Druck's unique range of resonant pressure sensor technology (TERPS) to ensure measurement accuracy inline with
the 12 month specification, removing the need for regular taring or vacuum resets Pressure ranges 750-1150 mbar (10.9-16.7 psi, 75-115 Kpa), absolute
- Pressure range 750-1150 mbar (10.9-16.7 psi, 75-115 Kpa), absolute
- Choice of precision up to 0.020 mbar or 0.0002901 psi
- Long term stability of 0.05 mBara/0.00073 psi per annum
- RS232, IEEE connectivity, Ethernet and USB as standard
- Min/max/average display
- Versatile, maintains performance with a wide range of environmental conditions and test media
Applications
- Atmospheric reference for pseudo absolute measurements – high accuracy barometer reduces the effect on the total uncertainty budget
- Tare of laboratory devices to a single reference
- Realtime measurement output for use in metrology applications and calculations
