The UNI-T UDP5160-16 is a single-channel 800W programmable DC switching power supply delivering 0–160V and 0–16A with auto-ranging across the rated power envelope. It pairs a wide output range with the regulation accuracy, source-emulation and remote control expected of a professional programmable supply.
Voltage accuracy is ±(0.05% of set + 0.05% of rated) and current accuracy ±(0.5% of set + 0.1% of rated); ripple is held to 50mV p-p with a 100 ppm/°C temperature coefficient. A 2.4-inch TFT-LCD shows voltage, current and power together, and full SCPI control over USB and LAN drops the UDP5040-200 straight into LabVIEW, Python-VISA or any ATE framework.
- 800W / 0–160V / 0–16A — auto-ranging across the rated power envelope
- Voltage accuracy ±(0.05% of set + 0.05% of rated); current accuracy ±(0.5% of set + 0.1% of rated)
- Low ripple — 100mV p-p voltage, 40mA rms current (20 MHz BW)
- CC/CV priority slope modes — choose voltage-first or current-first turn-on for DUT safety
- Adjustable internal resistance to 7.5Ω — emulate batteries, fuel cells and solar sources
- List Mode — 128 programmable V/I/dwell steps, 1 to 9,999, infinite cycles, stand-alone
- Front and rear output terminals (front limited to 10 A)
- Multi-unit series/parallel — up to 4 parallel / 4 series
- USB + LAN with full SCPI 1999.0 / IEEE-488.2; 2.4-inch TFT-LCD
- Discharge-load control for rapid output bleed-down
Applications
- Power-Electronics and SiC Development:0–160 V suits SiC half-bridge, PFC front-end and industrial three-phase intermediate-bus work where a stiff, low-ripple programmable rail is needed.
- EV-Charging and Industrial Subsystems: Internal-resistance emulation reproduces real source impedance for charger and converter validation; protection delay and OVP/OCP guard the DUT.
- Automated Test and Production: SCPI over USB or LAN plus stored List Mode sequences make the UDP5000 a clean fit for unattended characterisation, burn-in and end-of-line test.
Each Unit Includes
- power cord (destination-country standard, 1.8 m)
- four-conductor analog-interface flat cable (3.5 m)
- USB cable (1.5 m)
- M3 mounting screws
- output-terminal protection cover
- rack distribution bracket
