The EA-10000 Series programmable DC power supplies bring a host of capabilities and efficiencies to your application. Active power factor correction minimizes waste drawn from your power grid. True autoranging allows the delivery of maximum power along a wider range of voltage and current values while a suite of optional control interfaces enables computer control in near any manufacturing environment.
The EA PS and PSI programmable power supplies range in power from 1500W devices up to 30kW in a single chassis and feature 5" TFT Gorilla® Glass touchscreen displays for intuitive control and test setup. The power supplies can be paralleled for up to 3.84MW in output power at up to 2000VDC. The PSI Series comes standard with a built-in function generator capable of creating arbitrary waveforms, included test routines for battery test, fuel cell simulation, PV solar array simulation with MPP tracking, and other enhanced capabilities over the PS Series
EA-PSI 10920-20 3U is a programmable power supply able to deliver up to 920V and 20A with a power of 5000W. The EA-PSI 10920-20 3U has a high resolution with 16 bit ADCs.The power supply has a built-in function generator with multiple pre-configured waveforms. The device has multiple protective functions such as OPP, OCP, OVP and OTP and several included interfaces and multiple other interfaces are optional. The EA-PSI 10920-20 3U has temperature-controlled cooling that reduces the noise produced by adjusting the fan speed to the temperature inside the power supply. This power supply offers flexible "auto-ranging" which allows the power supply to offer a high current or a high voltage within the power offered. Additionally, the power supply can simulate batteries as single cells for optimal configuration of energy storage and you can program simulation models for solar cells including shadow, temperature and clouds. Finally, the power supply has a 5" TFT touchscreen display with an intuitive user interface.
- Models from 600W to 30kW, from 10V to 2000V and current capabilities up to 1000A
- Active power factor correction ensures energy recovery rates exceeding 96%, reducing operational costs and heat generation
- Units can be safely paralleled to create systems up to 3.84MW, offering scalability for large-scale applications
- Built-in function generator capable of simulating photovoltaic arrays, battery tests, and fuel cell emulation
- Compact Design: Available in 2U, 3U, and 4U
- MPPT, EN 50530, test sequences on LV123, LV124 and LV148 standards
- Easily programmable via SCPI or ModBus programming modes
- PC interfaces with Ethernet, USB and RS-232, PLC interfaces including CanBus, Profibus, ModBus, Profinet and EtherCat, among others
Applications
- Photovoltaic and Solar Testing
- Energy Storage & Battery Simulation
- Research and Development (R&D)
- Industrial Manufacturing & QA
Each Unit Includes
- Laboratory power supply 5KW 920V 20A 3U US208V (EA-PSI-10920-20-5KW)
- 2 - Remote sensing plugs
- 1 - 1.8 m (5.9 ft) USB cable
- 1 - Set of DC terminal covers
- 1 - Sense terminal cover
- 1 - USB stick with documentation and software
