Vitrek V73
Programmable AC/DC/IR HiPot Safety Tester

Order #: V73

Mfg #: V73

Questions about availability or need help? Contact Us:

(800) 633-0561
$3,294.20

Vitrek V73

Programmable AC/DC/IR HiPot Safety Tester

Order #: V73

Mfg #: V73

$3,294.20
Availability:
In stock

Choose Your Options:

Add Calibration

You have chosen to add the following Calibration Services to Your Order

Make sure your instrument is calibrated and ready to use the minute you open the box by adding our expert calibration service. Why Calibrate? For a complete descriptions of Transcat Service Levels, click here.

Already have this this item and need calibration? Request a calibration quote

This item is available as RENTAL at
Call for price
Shop now
This item is available USED at
Call for price
Shop now

Product Highlights

  • 5KV AC-DC Hipot Insulation Resistance Tester
  • 4.3" Color Touch Display—Easy To Use Intuitive User Interface
  • 6 Functions to Choose From—AC/DC Hipot, IR, Ground Bond, Continuity and Built-in Switching
  • Made in the USA—Designed and Built in San Diego CA
  •  Compact, Lightweight, Rugged, Fan Free, Fast (100mS min test time) and Accurate
  • 5KV AC/DC Hipot, 20mA max source current
  • Ground Bond 1-30A RMS (42 A peak), 100µΩ Resolution
  • 100 nano-Amp Leakage Current Resolution
  • Low Cost of Ownership—Two Year Calibration Interval
  • USB 2.0, Serial/RS232, Digital I/O Interfaces are Standard
  • Continuously Variable Insulation Resistance 20-5000V, 450GΩ Max
  • Multi Mode IR with Steady/Rising Pass Mode
  • Test Memory Stores up to 999 Steps and 60 Test Sequences
  • Internal Self Test Fully Exercises Output and Verifies Current Accuracy
  • Pre-Programmed Daily Verification Test With Optional PVD Test Load
  • 150µS Safety Shutdown
  • Ramped Discharge Capability
  • Selectable ARC Detection 1-20mA
  • Meets UL, CSA, IEC Safety Tester Requirements
  • CE Safety Mark Certified to EN61010
  • Two Year Parts and Labor Warranty
