Pomona EM5223-120 Lug Triax, Belden 9222 MTO Cable
Lug Triax,Belden 9222 MTO Cable

Order #: EM5223-120

Mfg #: 2662961

Questions about availability or need help? Contact Us:

(800) 633-0561
Special Price $255.23 Regular Price $296.79

Pomona EM5223-120 Lug Triax, Belden 9222 MTO Cable

Lug Triax,Belden 9222 MTO Cable

Order #: EM5223-120

Mfg #: 2662961

Special Price $255.23 Regular Price $296.79
Availability:
In stock
This product is available for shipping to the United States, Canada, and Puerto Rico only.
This product is available for shipping to the United States, Canada, and Puerto Rico only.
This product is available for shipping to the United States, Canada, and Puerto Rico only.

Product Highlights

  • Triaxial Cable Assembly Male Both Ends, 3 Lug
  • Length: 120"
  • Mates to Model #5219
  • 2 Shields provided for use in high interference areas
  • Lengths other than those specified available upon request

Materials:

  • Connection: 1st End: Triaxial Cable Male: BNC 3 Lug Bayonet Style
  • Finish: Body and Fittings - Tarnish Resistant
  • Intermediate and Center Contacts: Gold plated per requirements of MIL-C-39012
  • Cable: Belden 9222. Triaxial conductors, Nominal Impedance: 50 Ohms. 20 AWG, Polyethylene dielectric, Shield: Tinned Copper, Jacket: PVC, 6.15 (.242) O.D. Color: Yellow
  • Marking: "POMONA 5223"
  • Connection: 2nd End- Same as first

Ratings:

  • Operating Voltage: 500 VRMS/DC
  • Nominal Impedance of Cable: 50 Ohms

Triaxial cables are a standard accessory when conducting precise low-current testing. Triax cables feature a core and inner shield that are maintained at the same potential in order to practically eliminate current leakage. The Pomona EM5223-120# triaxial male 3 lugs cable assembly features tarnish resistant fittings and gold plated brass center contacts that meet MIL-C-39012 standards.
