The UNI-T UPO2000HDBW1MT2M is a factory-authorized bandwidth upgrade for select UNI-T UPO2000HD oscilloscopes. This upgrade boosts the analog bandwidth from 100 MHz to 200 MHz, unlocking the full performance potential of the hardware - without needing to replace your instrument.
If the user is probing fast digital signals, switch-mode power supplies, or RF-modulated waveforms, increasing bandwidth gives users sharper rise times, better visibility into high-frequency harmonics, and more accurate measurements at the signal edge.
- 200MHz Bandwidth Upgrade for UPO2100HD Oscilloscopes
- Switching Power Supplies: Capture fast edge transitions, detect ringing and overshoot
- UART and SPI Debugging: Observe cleaner waveform edges at higher baud rates
- PWM Signals: Analyze fast transitions and timing errors in motor drive control
- Clock Signals (e.g., 50-80 MHz): See harmonics and jitter effects clearly
- Embedded RF or Clock Leakage: Measure high-frequency coupling that 100 MHz would attenuate
- Rise Time (typical): Improves from ≤3.5 ns → ≤1.8 ns
Applications
- Electronics Development & Prototyping
- Embedded Systems / Microcontroller Circuits
- Power Electronics / Switching Circuits
- Signal Integrity and Analog Front-End Testing
- Educational / Lab Use
- Product Validation & Verification / QA
- Repair, Diagnostics & Troubleshooting
Each Unit Includes
- 1 - 100MHz to 200MHz Bandwidth Upgrade for UPO2100HD Oscilloscopes (UPO2000HD-BW1MT2M)
