The UNI-T MSO8000HDUSB2 USB Bus Trigger and Analysis option transforms the UNI-T MSO8000HD oscilloscope into a powerful USB 2.0 protocol analyzer, enabling comprehensive debugging and validation of USB 2.0 communications at speeds up to 480 Mbps. This professional-grade protocol decoder provides real-time decoding, intelligent triggering, and detailed packet analysis to quickly identify and resolve USB protocol issues during development, integration, and troubleshooting phases.
Designed for electronics engineers, embedded systems developers, and USB device manufacturers, the MSO8000HD-USB2 option eliminates the need for separate protocol analyzers by integrating powerful USB packet decoding with the precision measurement capabilities of the high-resolution oscilloscope. Accelerate USB device development and reduce debug time with this comprehensive analysis solution.
- Real-time decoding of USB 2.0 Low-Speed (1.5 Mbps), Full-Speed (12 Mbps), and High-Speed (480 Mbps) transmissions
- Intelligent protocol-aware triggering on packet types, endpoints, and data content
- Comprehensive packet analysis with color-coded protocol layers for intuitive visual interpretation
- Automatic identification of USB packet types: SOF, IN, OUT, SETUP, DATA, ACK, NAK, STALL
- Detailed packet field decoding including PID, ADDR, ENDP, CRC, and data payload
- Multi-level protocol view with frame, transaction, and transfer level perspectives
- Synchronized time-correlation between electrical signals and protocol information
- Error detection and highlighting for protocol violations and electrical signal issues
- Integration with MSO8000HD hardware-accelerated search for rapid protocol event location
- Statistical analysis tools for data throughput, error rates, and bus utilization measurements
- Export capabilities for decoded protocol data in CSV and text formats
- Support for bulk, control, interrupt, and isochronous transfer types
- Compatible with device, host, and hub analysis scenarios
- Compatible Models: MSO8804HD, MSO8504HD
- Installation: Software license activation - no hardware modification required
- Signal Requirements: USB D+/D- differential signals connected to oscilloscope channels
Applications
- USB 2.0 Protocol Decoding & Debugging
- USB-IF Compliance Testing
- Embedded Systems Development
- Signal Integrity & Jitter Analysis
- Manufacturing Validation
- Triggering on USB Data
Each Unit Includes
- 1 - USB Bus Trigger and Analysis Option (USB2.0) (MSO8000HD-USB2)
