The UNI-T MSO8000HDPCIe2 PCIe Bus Trigger and Analysis option provides comprehensive PCI Express protocol analysis capabilities for PCIe 1.0 and 2.0 interfaces, enabling engineers to decode, trigger on, and analyze PCIe communications with complete transaction-level visibility. This professional analysis tool delivers detailed insight into PCIe packet structure, link training sequences, and protocol performance, essential for validating PCIe-based communication systems and troubleshooting high-speed interconnect issues.
Designed for engineers working with computer systems, embedded computing, industrial automation, and high-speed data acquisition applications, the MSO8000HD-PCIe2 option combines advanced protocol decoding with the MSO8000HD's exceptional signal integrity analysis capabilities. This integration enables simultaneous analysis of PCIe transaction content and physical layer characteristics, providing complete visibility into both protocol compliance and signal quality for robust PCIe system validation.
- Complete PCIe 1.0 and 2.0 protocol decoding and analysis
- Transaction Layer Packet (TLP) analysis with header and payload decoding
- Data Link Layer Packet (DLLP) and Physical Layer analysis
- Link training and status state machine (LTSSM) monitoring
- Advanced triggering on PCIe-specific events and transaction types
- Credit-based flow control analysis and monitoring
- Error detection and recovery mechanism validation
- Lane deskew and symbol alignment analysis for multi-lane links
- Integration with signal integrity analysis for physical layer characterization
- Protocol search and navigation through extensive PCIe transaction captures
- Automated protocol analysis reporting with detailed transaction statistics
- Seamless integration with MSO8000HD's advanced measurement ecosystem
- Compatible Models: MSO8804HD, MSO8504HD
- Software license activation - no hardware modification required
- Supported Standards: PCI Express 1.0, 2.0 specifications
- PCIe differential lanes on oscilloscope analog channels
- Immediate functionality after activation
- Integration with all oscilloscope measurement and signal integrity capabilities
Applications
- Computer System Development
- Embedded Computing & Industrial Automation
- High-Speed Data Acquisition
- System Validation
Each Unit Includes
- 1 - PCIe Bus Trigger and Analysis Option (PCIe1.0, 2.0) (MSO8000HD-PCIe2)
