Product Highlights
The Hioki LR8534 provides 5 channels with a sampling rate of 1 ms. The wireless strain unit LR8533 can operate for about 5 hours on battery power. If the unit is charged at night, it can operate on the battery pack alone during the day.
The LR8534 cannot perform measurement by itself. Memory HiLogger LR8450-01 is required separately. By attaching the Z3230 Wireless LAN Adapter (accessory), LR8534 can be wirelessly connected to the Memory HiLogger LR8450-01.
Features
- For use with LR8450-01 Wireless LAN Multi-Channel Data Logger
- Suitable for convenient installation in testing equipment and confined locations
- Built-in buffer memory can hold up to 5 minutes of measurement data
- Operates for approximately 5 hours on battery power (sold separately)
- Number of channels: 5 (users can set voltage or strain for each channel)
- Maximum sampling rate: 1 ms
- Range (line of sight): 98.4 ft. (30 m)
- Input terminals: Push-button type terminal block (5 terminals per channel), outfitted with terminal block cover
- Measurement target: Voltage, strain
- Input type Balanced differential input, Simultaneous sampling of all channels (non-isolated channels)
- Dimensions (W x H x D): 6.06 x 4.17 x 2.24 in. (154 x 106 x 57 mm)
- Weight: 13.1 oz. (372 g)
