The UNI-T MSO5000HDAUDIO is an Audio Serial Bus Trigger and Analysis Option for MSO5000HD Oscilloscopes. With the MSO5000HD-AUDIO optional license, users can unlock real-time decoding and triggering for a range of digital audio buses including: I2S (Inter-IC Sound), LJ (Left Justified), RJ (Right Justified), TDM (Time Division Multiplexed Audio).
These protocols are widely used in embedded audio systems, consumer electronics, automotive infotainment, and digital signal processing applications. This option gives engineers a direct view into their audio data at the bit, word, and channel levels-essential for resolving tricky timing or data alignment issues.
- For use with MSO5000HD Oscilloscopes
- Decode left/right channel audio data streams in real time
- Visualize word select (WS), serial clock (SCK), and data lines (SD) with fully synchronized analysis
- Trigger on specific word values, channel ID, or data anomalies
- Automatically build event tables for frame-by-frame review
- Display waveform overlays showing timing alignment and decode results simultaneously
Applications
- Consumer Audio Electronics
- Embedded System
- Automotive Infotainment
- Professional Audio Equipment
- IoT and Smart Devices
- Chip and Codec Development
Each Unit Includes
- 1 - Audio Serial Bus Trigger and Analysis Option (MSO5000HD-AUDIO)
