Narda 3003-10 for Rent, Directional Coupler, 2 - 4GHz Coaxial

Narda 3003-10 Highlights

• RF Directional Coupler
• Low Frequency (GHz): 2.0
• High Frequency (GHz): 4.0
• Nominal Coupling (dB): 10
• Minimum Directivity (dB): 25
• Insertion Loss, Coupled Power Excluded (dB): 0.20
• True Insertion Loss (dB): 0.70
• VSWR Maximum for Primary Line: 1.15
• VSWR Maximum for Secondary Line: 1.20
• Calibration (Freq GHz): 2.0, 2.5, 3.0,3.5, 4.0
• Absolute Calibration Accuracy dB (per 10 dB step): +/- 0.1
• Maximum Deviation from Nominal (dB): +/- 1.2
• Power Incident (Watts): 200
• Power Reflected (Watts): 50
• Peak Power (kW): 10
