Megger DET14C Earth/Ground Clamp-on Resistance Tester
Earth/Ground Clamp-on Resistance Tester

Order #: DET14C

Mfg #: 1000-761

Questions about availability or need help? Contact Us:

(800) 633-0561
$3,087.00

Megger DET14C Earth/Ground Clamp-on Resistance Tester

Earth/Ground Clamp-on Resistance Tester

Order #: DET14C

Mfg #: 1000-761

$3,087.00
The Megger DET14C represents a new generation of earth ground clamp-on resistance testers. This instrument induces a test current into earth systems and measures ground resistance in multi ground installations without needing to disconnect the ground.

Be sure to Login to transcat.com for preferred member pricing.
Availability:
In stock

Choose Your Options:

Add Calibration

You have chosen to add the following Calibration Services to Your Order

Make sure your instrument is calibrated and ready to use the minute you open the box by adding our expert calibration service. Why Calibrate? For a complete descriptions of Transcat Service Levels, click here.

Already have this this item and need calibration? Request a calibration quote

This product is available for shipping to the United States and Canada only.

Product Highlights

  • 39 x 55 mm elliptical clamp shape improves access to earth cables and straps up to 50 mm
  • Low maintenance flat jaw design
  • Ground resistance range 0.05 Ω - 1500 Ω
  • AC current range 0.2 mA to 35A rms
  • 24 hour battery life based on continuous test at 25Ω, no backlight
  • CAT IV 600V safety rating
  • Backlight display

The DET14C and DET24C digital earth clamps represent a new generation of clamp-on resistance testers. These instruments induce a test current into earth systems and measure ground resistance in multi-ground installations without needing to disconnect the ground. They offer market leading access, advanced features, simple operation, and CAT IV 600 V safety protection.

This clamp-on stakeless earth tester can also:

  • Balance elements of a ground to mitigate noise
  • Balance ground circuits
  • Measure continuity of ground circuits in headends and hubs

The DET14C and DET24C also offer a true RMS AC current measurement facility up to 35 Amps. The instrument’s ability to measure current flowing in an earth cable is a useful safety feature, especially if the earth cable has to be disconnected.

The elliptical shaped head design offers improved access to cables and earth straps in space constrained locations. The clamp head accommodates up to 37 mm diameter cable and 50 mm earth tapes making them suitable for use in power stations, substations, towers, and many other facilities.

The DET14C can store results for later on-screen recall and with the DET24C, you can download results via Bluetooth® into PowerDB or PowerDB Lite (Megger's acceptance and maintenance test data management software). Stored data is indexed using a sequential serial number together with a time and date stamp for each record.

Each Unit Includes

  • Carrying case (2001-370)
  • Carrying strap - wrist loop (2001-054)
  • User guide CD-ROM (1001-198)
  • Calibration check accessory (1001-199)
