Overview
Product Highlights
Thinner cables are easy to use in confined spaces and with complicated wiring
Shaped so that it’s easy to route through complex wiring
Easily supports large current measurements up to 5000 A
Wide 10 Hz to 20 kHz band with excellent frequency characteristics
Combine with Hioki power meters or Memory HiCorders
180 mm (7.09 in)
Rated input current 5000 A AC/ 500 A AC
Max. allowable input 10000 A continuous (45 to 66 Hz, requires derating at frequency)
Bandwidth 10 Hz to 20 kHz (±3dB)
Amplitude and phase accuracy ±2 % rdg. ±0.3 % f.s. (45 to 66 Hz, at center of flexible loop) Phase: ±1 deg (45 to 66 Hz)
Output voltage 500 mV AC/f.s. (0.1 mV AC/A) at 5000 A range 500 mV AC/f.s. (1 mV AC/A) at 500 A range
Max. rated voltage to earth 1000 V AC (CAT III), 600 V AC (CAT IV)
Operating temperature -25 °C to +65 °C (-13 °F to 149 °F)
