UT220 series are 2000A AC/DC digital clamp meters. This series ensures stable performance, safety, and reliability for measuring up to 2000A AC (and DC for UT221) current. It is designed with over-load protection for all ranges, perfect for all professionals measuring currents up to 2000A (2500A for UT222).
The UNI-T UT222 is an advanced 2500A AC/DC digital clamp meter with enhanced accuracy and expanded measurement capabilities for professional electrical work. The UT222 features temperature measurement and superior current measurement accuracy up to 2500A.
- AC Current Range: 2500A ±(1.5%+5)
- DC Current Range: 2500A ±(1.5%+5)
- AC Voltage Range: 1000V ±(1%+3)
- DC Voltage Range: ±(0.5%+2)
- Resistance Range: 66MΩ ±(1%+2)
- Capacitance Range: 60mF ±(3%+5)
- Frequency Range: 20MHz ±(0.1%+3)
- Temperature Range: -40°C~1000°C ±(1%+10)
- Jaw Opening: 63mm
- True RMS AC Voltage/Current
- Auto Range Function
- Continuity Buzzer
- Data Hold and MAX/MIN
- Diode Testing
- Low Pass Filter
- Inrush Current Function
- 1000 Data Storage
- Analog Bar Graph
- Full Icon Display
Applications
- Industrial Equipment Maintenance
- Power Distribution & Utilities
- Electrical Installation & Commissioning
- Construction Site Inspection
- Field Service & Troubleshooting
Each Unit Includes
- 1 - True-RMS Digital AC/DC Clamp Meter, 1000V AC/DC, 2500A AC/DC Professional Grade (UT222)
- 1 - Set of Test Leads
- 1 - Output Cable
- 1 - Thermocouple
- 1 - Tool Box
- 1 - User Manual
