AEMC 8510
Digital Transformer Ratiometer, (110/220V)

Order #: 2136.50

Mfg #: 2136.50

Questions about availability or need help? Contact Us:

(800) 633-0561
Special Price $4,621.75 Regular Price $4,865.00

AEMC 8510

Digital Transformer Ratiometer, (110/220V)

Order #: 2136.50

Mfg #: 2136.50

Special Price $4,621.75 Regular Price $4,865.00

The DTR® Model 8510 is a portable digital transformer ratiometer designed for on-site testing of power, potential and current transformers. When connected to a non-energized transformer, the DTR® Model 8510 accurately measures primary to secondary turns ratio, while simultaneously displaying polarity and excitation current.

Availability:
In stock
This item is available as RENTAL at
Call for price
Shop now

Product Highlights

  • Ratio Testing: PT/VT from 0.8000:1 to 8000:1 and CT from 0.8000 to 1000.0 (Auto-Ranging)
  • Tests performed by exciting the primary and reading the secondary; provides safer conditions for the operator on step-down transformers
  • Continuity test indicates open or loose (high resistance) terminal connections
  • DC test mode eliminates errors due to magnetic build up
  • Stores up to 10 primary/secondary nameplate voltages to use in comparing test results
  • Displays ratio, test current, winding polarity, and deviation from nameplate voltage or ratio
  • Stores up to 10,000 test results
  • DataView® software included which allows configuring the instrument, downloading stored measurements and printing of test results in a report format
  • Display warns of incorrect lead connection, reverse polarity, open and short circuits
