The UNI-T MSO5000HDARINC429 is an ARINC49 Serial Bus Trigger and Analysis Option for MSO5000HD Oscilloscopes. MSO5000HD-ARINC429 unlocks full decode and trigger support for ARINC 429, the dominant data bus standard used in commercial aircraft for flight control, navigation, and system coordination.
ARINC 429 is a unidirectional, point-to-point bus that transmits 32-bit words using a self-clocking format. This decode option helps engineers decode, trigger, and analyze ARINC frames directly within the oscilloscope, dramatically reducing time-to-diagnosis.
- For use with MSO5000HD Oscilloscopes
- Decode ARINC 429 32-bit words in real time
- View label, SDI, data, and parity fields with full interpretation
- Trigger on label value, SDI, parity error, or user-defined data content
- Scroll through long captures with the event table view
- Identify missing or repeated words, signal glitches, or protocol anomalies
- Correlate analog faults (e.g., level distortion, reflections) with digital decoding
Applications
- Avionics Systems Design
- Aircraft Integration & Testing
- Aerospace R&D
- Maintenance and Diagnostics
- Simulators and Test Rigs
Each Unit Includes
- 1 - ARINC49 Serial Bus Trigger and Analysis Option (MSO5000HD-ARINC429)
