The UNI-T MSO5000HDAUTO adds Automotive CAN-FD, CAN-XL, FLEX and SENT Serial Bus Triggers and Analysis to MSO5000HD Oscilloscopes. With the MSO5000HD-AUTO software bundle, users gain a full suite of unlockable protocol decoders tailored specifically for modern and next-generation automotive systems.
From classic buses like CAN and LIN to emerging high-speed networks like CAN XL and FlexRay, this bundle enables users to analyze, trigger on, and debug communication across the entire in-vehicle data infrastructure-all without external analyzers or conversion tools.
- For use with MSO5000HD Oscilloscopes
- Adds Automotive CAN-FD, CAN-XL, FLEX and SENT Serial Bus Triggers and Analysis
- Each protocol is fully integrated into the MSO5000HD's decode engine, with waveform overlays, event tables, search tools, and exportable logs-ideal for time - correlated debugging of digital and analog behavior
Applications
- In-Vehicle Networking
- Automotive R&D
- Diagnostics & Maintenance
- Embedded Automotive Systems
- HIL / SIL Testing
Each Unit Includes
- 1 - CAN-FD Serial Bus Trigger and Analysis (MSO5000HD-CANFD)
- 1 - CAN-XL Serial Bus Trigger and Analysis (MSO5000HD-CANXL)
- 1 - FLEX Serial Bus Trigger and Analysis (MSO5000HD-FLEX)
- 1 - SENT Serial Bus Trigger and Analysis (MSO5000HD-SENT)
